Bag Filter for HVAC System
The medium efficiency bag filter is made of ultra-fine synthetic fiber with a special process to avoid possible harm to human body caused by the old glass fiber material. The filter material contains anti-static fiber, which is particularly good for filtering air dust particles. It has the advantages of large filtering area, high expiratory capacity and long service life.
1. Adopts ultra-fine synthetic fiber as filter material, large dust holding capacity, stable efficiency in the use cycle.
2. Melt-blown ultra-fine synthetic fiber filter media, and choose the optimized "v"-shaped structure bag filter, low resistance, long service life.
Frame: Galvanized sheet metal, Extruded anodized Aluminum profile, 20mm
Media: Synthetic fiber
Efficiency:
F5 (EN779):40-50% ASHRSE52/76
F6 (EN779):60-65% ASHRSE52/76
F7 (EN779):90% ASHRSE52/76
F8、F9(EN779):95% ASHRSE52/76
Temperature: ≤70℃
Humidity: ≤100%RH
Recommended Max Final Pressure drop: ≤450Pa
Applications:
Main filter for commercial & industrial ventilation system
Clean room MAU and AHU system
Automotive industry
Hotel and office building
| Bag Filter for HVAC System | ||||||||||
| Number | Model | L | W | H | Area | Airflow.pressure drop | Efficiency | |||
| mm | mm | mm | m2 | m3/h | Pa | m3/h | Pa | |||
| 1 | F55925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 55 | 3400 | 80 | F5 |
| 2 | F54905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 55 | 2700 | 80 | F5 |
| 3 | F54904903815 | 490 | 490 | 381*5 | 2.0 | 1700 | 55 | 2100 | 80 | F5 |
| 4 | F52875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 55 | 1700 | 80 | F5 |
| 5 | F55925925006 | 592 | 592 | 500*6 | 4.0 | 2500 | 50 | 3400 | 70 | F5 |
| 6 | F54905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 50 | 2700 | 70 | F5 |
| 7 | F54904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 50 | 2100 | 70 | F5 |
| 8 | F52875925003 | 287 | 592 | 500*3 | 2.0 | 1200 | 50 | 1700 | 70 | F5 |
| 9 | F55925926006 | 592 | 592 | 600*6 | 5.0 | 2500 | 50 | 3400 | 70 | F5 |
| 10 | F54905926005 | 490 | 592 | 600*5 | 4.0 | 2100 | 50 | 2700 | 60 | F5 |
| 11 | F54904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 50 | 2100 | 60 | F5 |
| 12 | F52875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 50 | 1700 | 60 | F5 |
| 13 | F65925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 80 | 3400 | 110 | F6 |
| 14 | F64905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 80 | 2700 | 110 | F6 |
| 15 | F64904903815 | 490 | 490 | 381*5 | 2.0 | 1700 | 80 | 2100 | 110 | F6 |
| 16 | F62875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 80 | 1700 | 110 | F6 |
| 17 | F65925925006 | 592 | 592 | 500*6 | 4.0 | 2500 | 75 | 3400 | 90 | F6 |
| 18 | F64905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 75 | 2700 | 90 | F6 |
| 19 | F64904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 75 | 2100 | 90 | F6 |
| 20 | F62875925003 | 287 | 592 | 500*3 | 2.0 | 1200 | 75 | 1700 | 90 | F6 |
| 21 | F65925926006 | 592 | 592 | 600*6 | 5.0 | 2500 | 60 | 3400 | 80 | F6 |
| 22 | F64905926005 | 490 | 592 | 600*5 | 4.0 | 2100 | 60 | 2700 | 80 | F6 |
| 23 | F64904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 60 | 2100 | 80 | F6 |
| 24 | F62875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 60 | 1700 | 80 | F6 |
| 25 | F75925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 100 | 3400 | 135 | F7 |
| 26 | F74905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 100 | 2700 | 135 | F7 |
| 27 | F74904903815 | 490 | 490 | 381*5 | 2.0 | 1700 | 100 | 2100 | 135 | F7 |
| 28 | F72875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 100 | 1700 | 135 | F7 |
| 29 | F75925925006 | 592 | 592 | 500*6 | 4.0 | 2500 | 100 | 3400 | 135 | F7 |
| 30 | F74905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 100 | 2700 | 125 | F7 |
| 31 | F74904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 100 | 2100 | 125 | F7 |
| 32 | F72875925003 | 287 | 592 | 500*3 | 2.0 | 1200 | 100 | 1700 | 125 | F7 |
| 33 | F75925926008 | 592 | 592 | 600*8 | 6.0 | 2500 | 100 | 3400 | 125 | F7 |
| 34 | F75925926006 | 592 | 592 | 600*6 | 5.0 | 2500 | 100 | 3400 | 125 | F7 |
| 35 | F74905926005 | 490 | 592 | 600*5 | 4.0 | 2100 | 95 | 2700 | 115 | F7 |
| 36 | F74904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 95 | 2100 | 115 | F7 |
| 37 | F72875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 95 | 1700 | 115 | F7 |
| 38 | F85925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 95 | 3400 | 115 | F8、F9 |
| 39 | F84905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 95 | 2700 | 115 | F8、F9 |
| 40 | F84904903815 | 490 | 490 | 381*5 | 2.0 | 1700 | 150 | 2100 | 190 | F8、F9 |
| 41 | F82875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 150 | 1700 | 190 | F8、F9 |
| 42 | F85925925006 | 592 | 592 | 500*6 | 4.0 | 2500 | 150 | 3400 | 190 | F8、F9 |
| 43 | F84905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 150 | 2700 | 190 | F8、F9 |
| 44 | F84904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 150 | 2100 | 190 | F8、F9 |
| 45 | F82875925003 | 287 | 592 | 500*3 | 2.0 | 1200 | 140 | 1700 | 170 | F8、F9 |
| 46 | F85925926008 | 592 | 592 | 600*8 | 6.0 | 2500 | 140 | 3400 | 170 | F8、F9 |
| 47 | F85925926006 | 592 | 592 | 600*6 | 5.0 | 2500 | 140 | 3400 | 170 | F8、F9 |
| 48 | F84905926005 | 490 | 592 | 600*5 | 4.0 | 2100 | 140 | 2700 | 170 | F8、F9 |
| 49 | F84904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 140 | 2100 | 170 | F8、F9 |
| 50 | F82875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 130 | 1700 | 150 | F8、F9 |
Glass fiber medium efficiency bag filter is not available at present.
Note: Pressure drop ±10%
| FAQ |
Q1: Can the product be customized?
A1: Yes, customized filters are available.
Q2: Are you a factory or trading company?
A2: We are Top 5 professional factory with rich experience in clean room engineering in China,and we have 15 patents for our products.
Q3: How long is the delivery time?
A3: It depends on the order quantity. Usually it takes about 7 to 15 working days after receiving your deposit.
Q4: How about the shipment?
A4: By sea, by air or by express, according to the Qty and your demand.
