Pocket Air Filter Performance
Medium filters for ventilating and air conditioning systems for commercial and industrial clean rooms, air supply systems for clean rooms, automotive Industries, hotels and office buildings.
Frame: Galvanized sheet metal, Extruded anodized Aluminum profile, 20mm
Media: Synthetic fiber
Efficiency:
F5 (EN779):40-50% ASHRSE52/76
F6 (EN779):60-65% ASHRSE52/76
F7 (EN779):90% ASHRSE52/76
F8、F9(EN779):95% ASHRSE52/76
Temperature: ≤70℃
Humidity: ≤100%RH
Recommended Max Final Pressure drop: ≤450Pa
Applications:
Main filter for commercial & industrial ventilation system
Clean room MAU and AHU system
Automotive industry
Hotel and office building
| Pocket Air Filter Performance | ||||||||||
| Number | Model | L | W | H | Area | Airflow.pressure drop | Efficiency | |||
| mm | mm | mm | m2 | m3/h | Pa | m3/h | Pa | |||
| 1 | F55925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 55 | 3400 | 80 | F5 |
| 2 | F54905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 55 | 2700 | 80 | F5 |
| 3 | F54904903815 | 490 | 490 | 381*5 | 2 | 1700 | 55 | 2100 | 80 | F5 |
| 4 | F52875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 55 | 1700 | 80 | F5 |
| 5 | F55925925006 | 592 | 592 | 500*6 | 4 | 2500 | 50 | 3400 | 70 | F5 |
| 6 | F54905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 50 | 2700 | 70 | F5 |
| 7 | F54904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 50 | 2100 | 70 | F5 |
| 8 | F52875925003 | 287 | 592 | 500*3 | 2 | 1200 | 50 | 1700 | 70 | F5 |
| 9 | F55925926006 | 592 | 592 | 600*6 | 5 | 2500 | 50 | 3400 | 70 | F5 |
| 10 | F54905926005 | 490 | 592 | 600*5 | 4 | 2100 | 50 | 2700 | 60 | F5 |
| 11 | F54904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 50 | 2100 | 60 | F5 |
| 12 | F52875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 50 | 1700 | 60 | F5 |
| 13 | F65925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 80 | 3400 | 110 | F6 |
| 14 | F64905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 80 | 2700 | 110 | F6 |
| 15 | F64904903815 | 490 | 490 | 381*5 | 2 | 1700 | 80 | 2100 | 110 | F6 |
| 16 | F62875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 80 | 1700 | 110 | F6 |
| 17 | F65925925006 | 592 | 592 | 500*6 | 4 | 2500 | 75 | 3400 | 90 | F6 |
| 18 | F64905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 75 | 2700 | 90 | F6 |
| 19 | F64904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 75 | 2100 | 90 | F6 |
| 20 | F62875925003 | 287 | 592 | 500*3 | 2 | 1200 | 75 | 1700 | 90 | F6 |
| 21 | F65925926006 | 592 | 592 | 600*6 | 5 | 2500 | 60 | 3400 | 80 | F6 |
| 22 | F64905926005 | 490 | 592 | 600*5 | 4 | 2100 | 60 | 2700 | 80 | F6 |
| 23 | F64904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 60 | 2100 | 80 | F6 |
| 24 | F62875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 60 | 1700 | 80 | F6 |
| 25 | F75925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 100 | 3400 | 135 | F7 |
| 26 | F74905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 100 | 2700 | 135 | F7 |
| 27 | F74904903815 | 490 | 490 | 381*5 | 2 | 1700 | 100 | 2100 | 135 | F7 |
| 28 | F72875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 100 | 1700 | 135 | F7 |
| 29 | F75925925006 | 592 | 592 | 500*6 | 4 | 2500 | 100 | 3400 | 135 | F7 |
| 30 | F74905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 100 | 2700 | 125 | F7 |
| 31 | F74904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 100 | 2100 | 125 | F7 |
| 32 | F72875925003 | 287 | 592 | 500*3 | 2 | 1200 | 100 | 1700 | 125 | F7 |
| 33 | F75925926008 | 592 | 592 | 600*8 | 6 | 2500 | 100 | 3400 | 125 | F7 |
| 34 | F75925926006 | 592 | 592 | 600*6 | 5 | 2500 | 100 | 3400 | 125 | F7 |
| 35 | F74905926005 | 490 | 592 | 600*5 | 4 | 2100 | 95 | 2700 | 115 | F7 |
| 36 | F74904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 95 | 2100 | 115 | F7 |
| 37 | F72875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 95 | 1700 | 115 | F7 |
| 38 | F85925923816 | 592 | 592 | 381*6 | 2.6 | 2500 | 95 | 3400 | 115 | F8、F9 |
| 39 | F84905923815 | 490 | 592 | 381*5 | 2.2 | 2100 | 95 | 2700 | 115 | F8、F9 |
| 40 | F84904903815 | 490 | 490 | 381*5 | 2 | 1700 | 150 | 2100 | 190 | F8、F9 |
| 41 | F82875923813 | 287 | 592 | 381*3 | 1.3 | 1200 | 150 | 1700 | 190 | F8、F9 |
| 42 | F85925925006 | 592 | 592 | 500*6 | 4 | 2500 | 150 | 3400 | 190 | F8、F9 |
| 43 | F84905925005 | 490 | 592 | 500*5 | 3.2 | 2100 | 150 | 2700 | 190 | F8、F9 |
| 44 | F84904905005 | 490 | 490 | 500*5 | 2.8 | 1700 | 150 | 2100 | 190 | F8、F9 |
| 45 | F82875925003 | 287 | 592 | 500*3 | 2 | 1200 | 140 | 1700 | 170 | F8、F9 |
| 46 | F85925926008 | 592 | 592 | 600*8 | 6 | 2500 | 140 | 3400 | 170 | F8、F9 |
| 47 | F85925926006 | 592 | 592 | 600*6 | 5 | 2500 | 140 | 3400 | 170 | F8、F9 |
| 48 | F84905926005 | 490 | 592 | 600*5 | 4 | 2100 | 140 | 2700 | 170 | F8、F9 |
| 49 | F84904906005 | 490 | 490 | 600*5 | 3.6 | 1700 | 140 | 2100 | 170 | F8、F9 |
| 50 | F82875926003 | 287 | 592 | 600*3 | 2.5 | 1200 | 130 | 1700 | 150 | F8、F9 |
Glass fiber medium efficiency bag filter is not available at present.
Note: Pressure drop ±10%
| FAQ |
Q1: Can the product be customized?
A1: Yes, customized filters are available.
Q2: Are you a factory or trading company?
A2: We are Top 5 professional factory with rich experience in clean room engineering in China,and we have 15 patents for our products.
Q3: How long is the delivery time?
A3: It depends on the order quantity. Usually it takes about 7 to 15 working days after receiving your deposit.
Q4: How about the shipment?
A4: By sea, by air or by express, according to the Qty and your demand.
